Cisco UCS 6324 Fabric Interconnect

Cisco UCS 6324 Fabric Interconnect

Cisco Unified Computing System Overview

The Cisco Unified Computing System (Cisco UCS®) is a next-generation data center platform that unites computing, networking, storage access, and virtualization resources into a cohesive system designed to reduce total cost of ownership (TCO) and increase business agility. The system integrates a low-latency, lossless 10 Gigabit Ethernet unified network fabric with enterprise-class, x86-architecture servers. The system is an integrated, scalable, multichassis platform in which all resources participate in a unified management domain (Figure 1).

The Cisco UCS 6324 Fabric Interconnect extends the Cisco UCS architecture into environments with requirements for smaller domains. Providing the same unified server and networking capabilities as in the full-scale Cisco UCS solution, the Cisco UCS 6324 Fabric Interconnect embeds the connectivity within the Cisco UCS 5108 Blade Server Chassis to provide a smaller domain of up to 20 servers.

Figure 1.      The Cisco Unified Computing System Is a Highly Available Cohesive Architecture

Product Overview

The Cisco UCS 6324 Fabric Interconnect Fabric Interconnect provides the management, LAN, and storage connectivity for the Cisco UCS 5108 Blade Server Chassis and direct-connect rack-mount servers. It provides the same full-featured Cisco UCS management capabilities and XML API as the full-scale Cisco UCS solution in addition to integrating with Cisco UCS Central Software and Cisco UCS Director (Figure 2).

From a networking perspective, the Cisco UCS 6324 Fabric Interconnect uses a cut-through architecture, supporting deterministic, low-latency, line-rate 10 Gigabit Ethernet on all ports, switching capacity of up to 500 Gbps, and 80-Gbps uplink bandwidth for each chassis, independent of packet size and enabled services. Sixteen 10-Gbps links connect to the servers, providing a 20-Gbps link from each Cisco UCS 6324 Fabric Interconnect to each server. The product family supports Cisco® low-latency, lossless 10 Gigabit Ethernet[1] unified network fabric capabilities, which increase the reliability, efficiency, and scalability of Ethernet networks. The fabric interconnect supports multiple traffic classes over a lossless Ethernet fabric from the blade through the fabric interconnect. Significant TCO savings come from a Fibre Channel over Ethernet (FCoE)-optimized server design in which network interface cards (NICs), host bus adapters (HBAs), cables, and switches can be consolidated.

Figure 2.      Cisco UCS Management Architecture

Unified Fabric with FCoE: I/O Consolidation

The Cisco UCS 6324 Fabric Interconnect is built to consolidate LAN and storage traffic onto a single unified fabric, eliminating the capital expenditures (CapEx) and operating expenses (OpEx) associated with multiple parallel networks, different types of adapter cards, switching infrastructure, and cabling within racks. The unified ports allow the fabric interconnect to support direct connections from Cisco UCS to Fibre Channel, FCoE, and Small Computer System Interface over IP (iSCSI) storage devices.

Cisco UCS Manager

The Cisco UCS 6324 Fabric Interconnect hosts and runs Cisco UCS Manager in a highly available configuration, enabling the fabric interconnects to fully manage all Cisco UCS elements. The Cisco UCS 6324 Fabric Interconnect Fabric Interconnects support out-of-band management through a dedicated 10/100/1000-Mbps Ethernet management port. Cisco UCS Manager typically is deployed in a clustered active-passive configuration on with two UCS 6324 Fabric Interconnects connected through the cluster interconnect built into the chassis.

Optimization for Virtualization

For virtualized environments, the Cisco UCS 6324 Fabric Interconnect supports Cisco virtualization-aware networking and Cisco Data Center Virtual Machine Fabric Extender (VM-FEX) architecture. Cisco Data Center VM-FEX allows the fabric interconnects to provide policy-based virtual machine connectivity, with network properties moving with the virtual machine and a consistent operational model for both physical and virtual environments.

Cisco UCS 6324 Fabric Interconnect

The Cisco UCS 6324 Fabric Interconnect Fabric Interconnect (Figure 3) is a 10 Gigabit Ethernet, FCoE, and Fibre Channel switch offering up to 500-Gbps throughput and up to four unified ports and one scalability port.

Figure 3.      Cisco UCS 6324 Fabric Interconnect

Table 1 summarizes the characteristics of the Cisco UCS 6324 Fabric Interconnect.

Table 1.       Characteristics of Cisco UCS 6324 Fabric Interconnect[2]

Item

Cisco UCS 6324

Description

Fabric interconnect with 4 unified ports and 1 scalability port

Form factor

I/O module for Cisco UCS 5108 chassis

Number of 1 and 10 Gigabit Ethernet, FCoE, or Fibre Channel Enhanced Small Form-Factor Pluggable (SFP+) external ports

4

Number of 40 Gigabit Ethernet or FCoE Enhanced Quad SFP (QSFP) ports

1

Server ports

16 x 10GBASE-KR lanes

Number of rack servers supported[3]

Single Cisco UCS 5108 Blade Server Chassis: 7

With second Cisco UCS 5108 Blade Server Chassis: 4

Throughput

500 Gbps

Latency

Less than a microsecond

Quality-of-service (QoS) hardware queues

16 (8 each for unicast and multicast)

Features and Benefits

Table 2 summarizes the features and benefits of the Cisco UCS 6324 Fabric Interconnect.

Table 2.       Features and Benefits

Feature

Benefit

Management by Cisco UCS Manager

●  Allows all elements connected to the interconnects to participate in a single, highly available management domain

Unified fabric

●  Decreases TCO by reducing the number of NICs, HBAs, switches, and cables needed
●  Transparently encapsulates Fibre Channel packets into Ethernet

Performance

●  Provides high-speed, low-latency connectivity to the chassis

Lossless fabric

●  Provides a reliable, robust foundation for unifying LAN and SAN traffic on a single transport

Priority flow control (PFC)

●  Simplifies management of multiple traffic flows over a single network link
●  Supports different classes of service, helping enable both lossless and classic Ethernet on the same fabric

Cisco Data Center VM‑FEX technology

●  Helps enable a consistent operational model for both virtual and physical environments
●  Provides the same level of network visibility for virtualized and nonvirtualized environments
●  Improves diagnostic and troubleshooting capabilities in a virtual environment
●  Simplifies network and security policy enforcement when migrating virtual machines from one host to another

SFP+ ports

●  Increases flexibility with a range of interconnect solutions, including copper Twinax cable for short runs and fiber for long runs
●  Consumes less power per port than traditional solutions
●  Helps enable cost-effective connections on fabric extenders with Cisco Fabric Extender Transceiver (FET) optics

SFP-compatible ports

●  Allows all fixed SFP+ ports to be configured to operate in 1 Gigabit Ethernet mode with the transceiver options specified for use with the SFP-compatible ports listed in Table 3

Product Specifications

Unified Port Transceivers

The Cisco UCS 6324 Fabric Interconnect supports a wide variety of 10 Gigabit Ethernet connectivity options using Cisco 10GBASE SFP+ modules. In addition, the four SFP+ uplink ports support 1 Gigabit Ethernet connectivity options using 1GBASE SFP modules. Alternatively, 2/4/8-Gbps Fibre Channel SFP+ interfaces are supported.

Table 3 lists the supported transceiver options.

Table 3.       Cisco UCS 6324 Fabric Interconnect Transceiver Support Matrix

Cisco SFP

Description

Cisco DS-SFP-FC4G-LW

4-Gbps Fibre Channel LW SFP, LC (10-km reach)

Cisco DS-SFP-FC4G-SW

4-Gbps Fibre Channel SW SFP, LC

Cisco DS-SFP-FC8G-LW

8-Gbps Fibre Channel LW SFP+, LC

Cisco DS-SFP-FC8G-SW

8-Gbps Fibre Channel SW SFP+, LC

Cisco GLC-T

1000BASE-T SFP

Cisco GLC-LH-SM

GE SFP, LC connector LX/LH transceiver (SMF) (for SFP-compatible ports only, as defined in Table 2)

Cisco GLC-SX-MM

GE SFP, LC connector SX transceiver (MMF) (for SFP-compatible ports only, as defined in Table 2)

Cisco GLC-T

1000BASE-T SFP (for SFP-compatible ports only, as defined in Table 2)

Cisco SFP-10G-AOC10M

10GBASE active optical SFP+ cable, 10m

Cisco SFP-10G-AOC1M

10GBASE active optical SFP+ cable, 1m

Cisco SFP-10G-AOC3M

10GBASE active optical SFP+ cable, 3m

Cisco SFP-10G-AOC5M

10GBASE active optical SFP+ cable, 5m

Cisco SFP-10G-AOC7M

10GBASE active optical SFP+ cable, 7m

Cisco SFP-10G-LR

10GBASE-LR SFP module

Cisco SFP-10G-LR-X

10GBASE-LR SFP module for extended temperature range

Cisco SFP-10G-SR

10GBASE-SR SFP+ module (multimode fiber [MMF])

Cisco SFP-10G-SR-X

10GBASE-SR SFP+ transceiver module for MMF, 850-nm wavelength, LC duplex connector, extended temperature range

Cisco SFP-H10GB-ACU10M

10GBASE-CU SFP+ cable, 10m (Twinax cable)

Cisco SFP-H10GB-ACU7M

10GBASE-CU SFP+ cable, 7m (Twinax cable)

Cisco SFP-H10GB-CU1M

10GBASE-CU SFP+ cable, 1m (Twinax cable)

Cisco SFP-H10GB-CU2M

10GBASE-CU SFP+ cable, 2m (Twinax cable)

Cisco SFP-H10GB-CU3M

10GBASE-CU SFP+ cable, 3m (Twinax cable)

Cisco SFP-H10GB-CU5M

10GBASE-CU SFP+ cable, 5m (Twinax cable)

Scalability Port Transceivers

The Cisco UCS 6324 Fabric Interconnect supports a QSFP+ port that provides connectivity for up to 4 Cisco UCS rack servers. Table 4 lists the transceiver options support by the scalability port.

Table 4.       QSFP+ Transceiver Support Matrix

QSFP-4SFP10G-CU1M

40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable assemblies, 1m passive

QSFP-4SFP10G-CU3M

40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable assemblies, 3m passive

QSFP-4SFP10G-CU5M

40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable assemblies, 5m passive

QSFP-40G-SR4

40GBASE-SR4, 4 lanes, 850 nm MMF QSFP transceiver nodule with MPO connector

QSFP-4x10G-AC10M

40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable assemblies, 10m active

QSFP-4x10G-AC7M

40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable assemblies, 7m active

QSFP-4X10G-AOC10M

40GBASE active optical QSFP to 4SFP breakout cable, 10m

Cabling

Table 5 provides cabling specifications for the Cisco UCS 6324 Fabric Interconnect.

Table 5.       Cabling Specifications

Connector (Media)

Cable

Distance

Power (Each Side)

Transceiver Latency (Link)

Standard

SFP+ copper (CU)

Twinax

1, 3, 5, 7, and 10m

Approximately 0.1 watt (W)

Approximately 0.1 microsecond

SFF 8431

SFP+ short reach (SR) and MMF

MM OM2

MM OM3

MM OM4

82 and 300m

1W

Approximately 0 microseconds

IEEE 802.3ae

QSFP+ copper (CU)

Twinax

1, 3, 5, 7, and 10m

1.5W

Approximately 0.1 microsecond

SFF 8635

Performance

●   Cisco UCS 6324 Fabric Interconnect: Layer 2 hardware forwarding at 500 Gbps or 375 million packets per second (mpps)

●   MAC address table entries: 20,000

●   Low-latency cut-through design: Provides predictable, consistent traffic latency regardless of packet size, traffic pattern, or enabled features

Layer 2

●   Layer 2 interconnect ports and VLAN trunks

●   IEEE 802.1Q VLAN encapsulation

●   Support for up to 512 VLANs and 32 virtual SANs (VSANs) per interconnect

●   Internet Group Management Protocol (IGMP) Versions 1, 2, and 3 snooping

●   Link Aggregation Control Protocol (LACP): IEEE 802.3ad

●   Advanced EtherChannel hashing based on Layer 2, 3, and 4 information

●   Jumbo frames on all ports (up to 9216 bytes)

●   Pause frames (IEEE 802.3x)

QoS

●   Layer 2 IEEE 802.1p (class of service [CoS])

●   CoS trust

●   CoS-based egress queuing

●   Egress port-based scheduling: Deficit Weighted Round-Robin (DWRR)

●   16 hardware queues (8 each for unicast and multicast)

High Availability

●   Two Cisco UCS 6324 Fabric Interconnect Fabric Interconnects can be clustered together within the chassis to provide a highly available interconnect system

●   Firmware upgrades can be performed on each fabric interconnect independently, allowing server connectivity to be maintained while firmware upgrades are completed

Management

●   Interconnect management using redundant 10/100/1000-Mbps management or console ports

●   All management provided through Cisco UCS Manager; please refer to the Cisco UCS Manager data sheet for more information about management interfaces

Data Center Bridging 10 Gigabit Ethernet Unified Network Fabric

●   IEEE 802.1QPFC (per-priority pause frame support)

●   Data Center Bridging Exchange (DCBX) Protocol

●   IEEE 802.1Qaz: Bandwidth management

Unified Ports

●   All 4 SFP+ ports configurable as 1/10 Gigabit Ethernet or 2/4/8-Gbps Fibre Channel

Industry Standards

●   IEEE 802.1p: CoS prioritization

●   IEEE 802.1Q: VLAN tagging

●   IEEE 802.3: Ethernet

●   IEEE 802.3ad: LACP

●   IEEE 802.3ae: 10 Gigabit Ethernet

●   IEEE 802.1AB LLDP

●   SFP+ support

●   RMON

Physical Specifications

SFP+ Optics

Cisco UCS products support 10 Gigabit Ethernet SFP+ copper Twinax cables for short distances and SFP+ optics for longer distances. SFP+ has several advantages compared to other 10 Gigabit Ethernet connectivity options:

●   Small 10 Gigabit Ethernet form factor

●   Optical interoperability with XENPAK, X2, and 10 Gigabit Small Form-Factor Pluggable (XFP) interface types

●   Low power consumption

●   Hot-swappable device

Cisco UCS 6324 Fabric Interconnect Physical and Environmental Specifications

Table 6 summarizes the physical and environmental specifications for the Cisco UCS 6324 Fabric Interconnect.

Table 6.       Physical and Environmental Specifications

Property

Cisco UCS 6324

Physical (height x width x depth)

7.64 x 1.36 x 7.2 in. (194 x 34.5 x 183 mm)

Ambient Operating temperature

32 to 95°F (0 to 35°C)

Nonoperating temperature

-40 to 158°F (-40 to 70°C)

Humidity

5 to 95% (noncondensing)

Altitude

0 to 10,000 ft (0 to 300m)

Weight

2.5 lb (1.134 kg)

Regulatory Standards Compliance: Safety and EMC

Table 7 summarizes Cisco UCS 6324 Fabric Interconnect regulatory compliance.

Table 7.       Regulatory Standards Compliance

Specification

Description

Regulatory compliance

Products complies with CE Markings according to directives 2004/108/EC and 2006/95/EC

Safety

●  UL 60950-1
●  CAN/CSA-C22.2 No. 60950-1
●  EN 60950-1
●  IEC 60950-1
●  AS/NZS 60950-1
●  GB4943

EMC: Emissions

●  47CFR Part 15 (CFR 47) Class A
●  AS/NZS CISPR22 Class A
●  CISPR22 Class A
●  EN55022 Class A
●  ICES003 Class A
●  VCCI Class A
●  EN61000-3-2
●  EN61000-3-3
●  KN22 Class A
●  CNS13438 Class A

EMC: Immunity

●  EN50082-1
●  EN61000-6-1
●  EN55024
●  CISPR24
●  EN300386
●  KN 61000-4 series

RoHS

The product is RoHS 6-compliant

Warranty Information

Warranty information is provided at Cisco.com on the Product Warranties page.

Cisco Unified Computing Services

Using a unified view of data center resources, Cisco and our industry-leading partners deliver services that accelerate your transition to a unified computing environment. Cisco Unified Computing Services helps you quickly deploy your data center resources and optimize ongoing operations to better meet your business needs. For more information about these and other Cisco Data Center Services, visithttp://www.cisco.com/go/dcservices.

Why Cisco?

Cisco has significant experience in listening to customer requirements and providing solid technology innovation for the enterprise data center. Cisco delivers standards-based solutions backed by a broad partner ecosystem of industry leaders to provide end-to-end customer solutions. Unified computing elevates the traditional product classification of network, server, storage, operating systems, and applications to a vision that encompasses the whole data center. Cisco, as one of the largest technology providers in the world, has the resources, expertise, and customer focus to deliver on this vision.

Cisco Capital

Financing to Help You Achieve Your Objectives

Cisco Capital can help you acquire the technology you need to achieve your objectives and stay competitive. We can help you reduce CapEx. Accelerate your growth. Optimize your investment dollars and ROI. Cisco Capital financing gives you flexibility in acquiring hardware, software, services, and complementary third-party equipment. And there’s just one predictable payment. Cisco Capital is available in more than 100 countries. Learn more.

For More Information

For more information about the Cisco UCS 6324 Fabric Interconnect, visithttp://www.cisco.com/en/US/products/ps10276/index.html or contact your local account representative.

Byadmin

2.VMware Horizon View 6

2.VMware Horizon View 6

نرم افزار VMware Horizon 6.2 که نسخه جدید مجازی سازی دسکتاپ می باشد دارای قابلیت های جدیدتری نسبت به ورژن های قبلی خود دارد که از آنها می توان به ویژگی های جدید در سرور ها و کلاینت ها و پلترف اشاره نمود.

از قابلیت های جدید این نرم افزار در حوزه پلتفرم سروری می توان به موارد ذیل اشاره نمود:

  • قابلیت های افزونه RDSH شامل Linked Clone و 3D و پشتیبانی از Load Balancing
  • معماری Cloud شامل قابلیت های HTML Access و RDSH
  • مزایای عمومی FIPS
  • AD Trust یکطرفه
  • سهولت در ایجاد Pool
  • اطلاعات کامل لایسنسی



از قابلیت های جدید این نرم افزار در حوزه کلاینت می توان به موارد ذیل اشاره نمود:

  • قابلیت Redirect نمودن Client Drive برای Mac
  • قابلیت Redirect نمودن Client Drive برای لینوکس
  • قابلیت Encryption و Compression برای Client Drive Redirection
  • پیوستگی انواع فایل برای برنامه های RDS
  • پشتیبانی از ThinPrint Static Printer Name
  • پشتیبانی از ویندوز 10
  • پشتیبانی از “OSX 10.11 “El Capitan
  • پشتیبانی از iOS 9
  • پشتیبانی فوق العاده از موبایل
  • پشتیبانی از Linux Desktop NVIDIA GRID vGPU
  • پشتیبانی از Linux Desktop vSGA
  • Linux Desktop Guest Logoff Automation
  • پشتیبانی از 4K Guest Resolution
  • پشتبانی از MS Lync و Skype



از قابلیت های جدید این نرم افزار در حوزه کلاینت می توان به موارد ذیل اشاره نمود:

  • vDGA for AMD Hardware
  • Access Point Integration
  • vSphere 6.0 U1 Support
  • Virtual SAN All Flash Support
  • Virtual SAN Stretched Cluster Support
  • Enhanced VMware UEM Integration



به روشنی می توان گفت این نسخه از نرم افزار VMware Horizon قابلیت های کلیدی را پشتیبانی می کند.

در ابتدا در مورد قابلیت های پلتفرم سرور توضیحاتی را می دهیم.

نرم افزار VMware Horizon نرم افزار های Publish شده ای را در داخل Horizon 6 عرضه می کند.

نرم افزار Horizon اکنون مدیریت متمرکزی برای VDI و RDSH فراهم می سازد.

در هاستهای RDS 6.2 می توان بوسیله View Composer عملیات Provisioning را انجام داد و این امکان به ما اجازه می دهد تا با مدیریت یک Image و ایجاد چندین هاست RDS از آخرین امکانات موجود استفاده نماییم.

View-Composer-RDSH-مجازی-سازی-دسکتاپ



دسکتاپ کاربر با RDSH نیز بواسطه پشتیبانی از نرم افزار های 3D ارتقا یافته است. یک RDSH می تواند به یک NVIDIA GRID vGPU وصل شده و بتواند نرم افزار های گرافیکی خود را اجرا کند. کلیه این قابلیت ها از طریق پروتکل PCoIP انجام می گیرد.

نرم افزار کسب و کار Skype در ساختار Lync بر روی RDS پشتیبانی می شود و از این طریق راهکاری بسیار ارزان قیمت و بهینه در اختیار کاربر قرار می دهد.

در مورد RDSH می توان گفت که قابلیت Load Balancing  برای فرمهای RDSH دارد. مدیران شبکه اکنون می توانند سرور های خود را از لحاظ پردازنده و حافظه و خیلی پارامتر های دیگر Load Balance بکنند. با توجه به امکان استفاده از رول های Affinity و Anti-Affinity می توان یک ساختار LB فوق العاده در بین هاستهای RDS برقرار کنند.

معماری Cloud که اکنون بسیاری از دیتاسنتر های دنیا را درگیر خود ساخته است و لزومه استفاده از Horizon نیز می باشد باید گفت که این نرم افزار قابلیت دسترسی به دسکتاپ کاربر از طریق HTML Access و Web Browser را دارد.

در ساختارهای ابری VDI کاربر در صورت بروز خطا در یک دیتاسنتر می توانند همان لحظه دسکتاپ مجازی خود را در یک دیتاسنتر دیگر مشاهده کنند.



cloud-pod-architecture-RDS-مجازی-سازی-ابری



از منظر کاربر می توان مزایای جدیدی بر این نرم افزار برشمرد. همانطور که گفته شد این نرم افزار قابلیت پشتیبانی برای ویندوز 10 و iOS9 را دارد.

Client-Drive-Redirection-VDI-RDSH-مجازی-سازی-دسکتاپ

در خصوص دسکتاپ لینوکس نیز قابلیت های فراوانی همچون vSGA  و vGPU 3D و نیز پشتیبانی از NVIDIA GRID VGPU به سیستم اضافه شده است.

گروه فنی و مهندسی وی سنتر ارائه دهنده راهکارهای مجازی سازی دسکتاپ از مشتریان خود را به مشاهده و استفاده از لابراتوار آنلاین خود به آدرس زیر دعوت می کند.

ورود-به-لابراتوار-آنلاین

برای کسب اطلاعات بیشتر با ما تماس بگیرید.

شماره تماس: 88884268

Byadmin

HP 3PAR StoreServ 20000 Storage

HP 3PAR StoreServ 20000 Storage

Have Cloud and ITaaS environments forced you to settle for Tier-1 storage that compromises on performance and scalability? Interested in processing 6x more transactions per second with 90% fewer disks? HPE 3PAR StoreServ 20000 Storage is a new class of enterprise flash arrays with greater than 3M IOPS, sub-millisecond latencies, a 6x density advantage, and scalability of over 20 PiB of usable capacity for massive consolidation. The flash-optimized architecture features the HPE 3PAR Gen5 Thin Express ASIC for hardware accelerated thin technologies, including inline deduplication to cut capacity requirements by up to 75%.

Options support true convergence of block and file protocols, all-flash array performance, and the use of SSDs with spinning media for unmatched versatility. Enhanced Tier-1 storage capabilities and QoS controls ensure predictable service levels for all workload types while bi-directional data mobility enables virtually limitless elastic pools of storage.

What’s new

  • Mix and match flash and HDDs at will with a Flash-optimized architecture for over 3M IOPS @ <1ms latency and scalability of over 20 PiB usable with the HPE 3PAR StoreServ 20840 Converged Flash array.
  • Get 276 TB usable capacity per rack unit, 6x density advantage vs legacy storage, with the new 7.68 TB SSD.
  • Take advantage of flash for less than $100K (USD) with HPE 3PAR StoreServ 20800 Flash Starter Kit.
  • Reduce capacity requirements by up to 75% guaranteed when migrating from legacy storage to 3PAR StoreServ Storage with the HPE Get Thinner program.
  • Provision block storage volumes as well as file shares from a single capacity store with HPE 3PAR File Persona Software Suite.

Features

Scalable to Meet Growing Enterprise Requirements

Scale capacity up to 9 PiB raw and over 20 PiB usable with up to eight controllers in a Mesh-Active cluster.
Reduce performance bottlenecks with flash-optimized hardware and software for greater than 3 million IOPS at sub-millisecond latencies.
Lower the cost of all-flash to $1.50 USD per GB usable without sacrificing performance.
Achieve a 6X density advantage or more with over 9 PiB of usable capacity in a single expansion rack.
Cut capacity requirements 75 percent without sacrificing performance.

Flexible to Meet Unpredictable Business Demands

Support the most rigorous, on-demand infrastructure with a virtually limitless, elastic pool of storage.
Run workloads at the right cost and SLA with one-click workload balancing.
Slash management overhead with unified management of block, file, and object access and storage that is self-configuring, self-provisioning, and self-optimizing.

Resilient so you can Consolidate with Confidence

Maintain high availability and Tier-1 resiliency with a complete set of persistent technologies.
Deliver consistent QoS with HPE 3PAR Priority Optimization Software.
Achieve application-integrated recovery with near-synchronous RPOs.
Simplify backup and restore with HPE StoreOnce Recovery Manager Central for application-aware, storage-integrated data protection.

Futureproof to Support Hybrid and On-demand Computing

Modernize your EMC, HDS, and IBM storage infrastructure with painless, no-cost data migration.
Seamlessly move data between any model HPE 3PAR StoreServ Array.
Boost flash performance by 35 percent and reduce latency by 2.5x with 16 Gbps Fibre Channel.
  • IBM® is trademark of IBM Corporation in the United States and/or other countries.
  • Apple® is a trademark of Apple Inc., registered in the U.S. and other countries.
  • Hyper-V® is a registered trademark of Microsoft Corporation in the United States and other countries.
  • Citrix® is a trademark and/or registered trademark of Citrix Systems, Inc. in the United States and other countries.
  • Red Hat® Enterprise Linux® Red Hat is a trademark of Red Hat, Inc. in the U.S. and other countries. Linux is a registered trademark of Linus Torvalds.
  • Ubuntu® is a registered trademark of Canonical Ltd.
  • VMware® is a registered trademark of VMware, Inc. in the United States and/or other jurisdictions.
  • Hyper-V® is a registered trademark of Microsoft Corporation in the United States and other countries.
  • Oracle® is a trademark of Oracle Corporation in the U.S. and other countries.
